Endopore & Entegra External Hex





Innova Endopore® & Entegra® compatible external hex parts

Enter the REF number from the implant label (e.g. 01WB-712), or pick the platform.



Check before you order: 4.1 mm Endopore implants made before 2000 (01 range, grey label) take different parts than 01B implants (green label). Search the REF number on the label.

  • FDA-cleared
  • Made in the USA
  • Ships same day by 4 PM ET
  • Since 2000

Need help matching a part? 1-201-439-0470

3.5 mm platform

Endopore 3.5 (01M, red label) and Entegra 3.25 (03M). 0.9 mm high × 2.0 mm hex, UNF thread.

SR-35HA-IPHealing abutmentSR-35HA-IPCross-ref: 02M-3HS, 02M-5HS +3IP-3.5SLIAFStraight abutmentIP-3.5SLIAFCross-ref: 05M-7FS, 05M-7FN +1IP-35IICImpression coping, long screwIP-35IICCross-ref: 06M-CTCA/S, 06M-CTCA/SL +1IP-35IA-ALImplant analogIP-35IA-ALCross-ref: 06M-IA/1, 06M-IA +2IP-35PSUCLA plastic sleeve, hex and non-hexIP-35PSCross-ref: 06M-UCLA/H, 06M-UCLA +2Ball abutmentIE-5-3EBHACross-ref: 04M-1ORS, 04M-2ORS +3Ball abutmentIE-5-3EBHA-BHSR-IP-35CA-12Bar abutment (laser-weld)SR-IP-35CA-12
Innova part number cross-reference (24)
Innova part number cross-reference
Innova part Description Titan part
02M-3HS Straight healing abutment, H 3, 3.5 EP SR-35HA-IP
02M-5HS Straight healing abutment, H 5, 3.5 EP SR-35HA-IP
02M-7HS Straight healing abutment, H 7, 3.5 EP SR-35HA-IP
02M-4H Flared healing abutment, H 4, 4.5 EP SR-35HA-IP
02M-6.5H Flared healing abutment, H 6.5, 4.5 EP SR-35HA-IP
06M-CTCA/S Straight transfer coping, 11 mm IP-35IIC
06M-CTCA/SL Straight transfer coping, 16 mm IP-35IIC
06M-CTCA/F Flared transfer coping IP-35IIC
06M-IA/1 Implant analog, aluminum IP-35IA-AL
06M-IA Implant analog, aluminum, 5 pack IP-35IA-AL
06M-PIA Implant analog, stainless IP-35IA-AL
06M-PIA/5 Implant analog, stainless, 5 pack IP-35IA-AL
05M-7FS Straight hexed abutment IP-3.5SLIAF
05M-7FN Straight hexed abutment IP-3.5SLIAF
05M-9FN Straight hexed abutment IP-3.5SLIAF
06M-UCLA/H UCLA, hexed IP-35PS
06M-UCLA UCLA, non-hexed IP-35PS
06M-UCLA/H/G Gold UCLA, hexed, all-plastic alternative IP-35PS
06M-UCLA/G Gold UCLA, non-hexed, all-plastic alternative IP-35PS
04M-1ORS O-ring abutment, 1 mm cuff IE-5-3EBHA
04M-2ORS O-ring abutment, 2 mm cuff IE-5-3EBHA
04M-3ORS O-ring abutment, 3 mm cuff IE-5-3EBHA
04M-4ORS O-ring abutment, 4 mm cuff IE-5-3EBHA
04M-5ORS O-ring abutment, 5 mm cuff IE-5-3EBHA
Innova implant numbers for 3.5 mm (10)

4.1 mm platform, 2000 and later

Endopore 01B (green label), Endopore Hybrid and Entegra 03B. Industry-standard 0.7 × 2.7 mm hex, metric thread.

T-4HA-A-1.0-IPCover screwT-4HA-A-1.0-IPCross-ref: 02B-CSIE-5-4EHA1Healing abutment, 4.5 mm EPIE-5-4EHA1Cross-ref: 02B-3HS, 02B-5HS +1IE-5-4EHA2Healing abutment, 5 mm EPIE-5-4EHA2Cross-ref: 02B-4H, 02B-6.5HIE-5-4EHA3Healing abutment, 6 mm EPIE-5-4EHA3T-4SLIAF-IPStraight abutmentT-4SLIAF-IPCross-ref: 05B-7FS, 05B-7FN +4T-4PA-IPPost abutmentT-4PA-IPT-4PABR-IPPost abutment, bite registrationT-4PABR-IPT-4ESA-IPSimple Step abutmentT-4ESA-IPNB-MCAS-IPMulti-unit abutment, engagingNB-MCAS-IPT-4TA-IPTemporary abutmentT-4TA-IPCross-ref: 05B-TEMP/H, 05B-TEMPT-4IIC-IPImpression coping, guide pinT-4IIC-IPCross-ref: 06B-CTCA/S, 06B-CTCA/SL +2T-4IAT-IPImplant analogT-4IAT-IPCross-ref: 06B-IA/1, 06B-IA +2T-4PS-IPUCLA plastic sleeve, hex and non-hexT-4PS-IPCross-ref: 06B-UCLA/H, 06B-UCLA +2IE-4EBHABall abutmentIE-4EBHACross-ref: 04B-1ORS, 04B-2ORS +5NB-4CA-12-IPBar abutment (laser-weld)NB-4CA-12-IPSRS-43BHAABall abutment analogSRS-43BHAA

For the multi-unit abutment

NB-MUABPMUA bar abutment (laser-weld)NB-MUABPNB-MUTASMUA temporary sleeveNB-MUTASNB-3.3/4.0MCRMUA analogNB-3.3/4.0MCRNB-3.3/4.0MICMUA impression copingNB-3.3/4.0MIC
Innova part number cross-reference (33)
Innova part number cross-reference
Innova part Description Titan part
02B-CS Cover screw T-4HA-A-1.0-IP
02B-3HS Straight healing abutment, H 3, 4.1 EP IE-5-4EHA1
02B-5HS Straight healing abutment, H 5, 4.1 EP IE-5-4EHA1
02B-7HS Straight healing abutment, H 7, 4.1 EP IE-5-4EHA1
02B-4H Flared healing abutment, H 4, 5.3 EP IE-5-4EHA2
02B-6.5H Flared healing abutment, H 6.5, 5.3 EP IE-5-4EHA2
06B-CTCA/S Straight transfer coping, 11 mm T-4IIC-IP
06B-CTCA/SL Straight transfer coping, 16 mm T-4IIC-IP
06B-CTCA/F Flared transfer coping, 11 mm T-4IIC-IP
06B-CTCA/FL Flared transfer coping, 16 mm T-4IIC-IP
06B-IA/1 Implant analog, aluminum T-4IAT-IP
06B-IA Implant analog, aluminum, 5 pack T-4IAT-IP
06B-PIA Implant analog, stainless T-4IAT-IP
06B-PIA/5 Implant analog, stainless, 5 pack T-4IAT-IP
05B-7FS Straight hexed abutment T-4SLIAF-IP
05B-7FN Straight hexed abutment T-4SLIAF-IP
05B-9FS Straight hexed abutment T-4SLIAF-IP
05B-9FN Straight hexed abutment T-4SLIAF-IP
05B-11FS Straight hexed abutment T-4SLIAF-IP
05B-11FN Straight hexed abutment T-4SLIAF-IP
05B-TEMP/H Temporary abutment, hexed T-4TA-IP
05B-TEMP Temporary abutment, non-hexed T-4TA-IP
06B-UCLA/H UCLA, hexed T-4PS-IP
06B-UCLA UCLA, non-hexed T-4PS-IP
06B-UCLA/H/G Gold UCLA, hexed, all-plastic alternative T-4PS-IP
06B-UCLA/G Gold UCLA, non-hexed, all-plastic alternative T-4PS-IP
04B-1ORS O-ring abutment, 1 mm cuff IE-4EBHA
04B-2ORS O-ring abutment, 2 mm cuff IE-4EBHA
04B-3ORS O-ring abutment, 3 mm cuff IE-4EBHA
04B-4ORS O-ring abutment, 4 mm cuff IE-4EBHA
04B-5ORS O-ring abutment, 5 mm cuff IE-4EBHA
04B-6ORS O-ring abutment, 6 mm cuff IE-4EBHA
04B-7ORS O-ring abutment, 7 mm cuff IE-4EBHA
Innova implant numbers for 4.1 mm (32)

4.1 mm platform, before 2000

Original Endopore 01 range (grey label). 0.9 mm high hex and UNF thread: these do not take standard 4.1 mm parts.

C-3.75/4HAHealing abutmentC-3.75/4HAImpression copingIE-O-4EIICIE-O-4EIA-ALImplant analogIE-O-4EIA-ALIE-O-4ESA-IPSimple Step abutmentIE-O-4ESA-IPBall abutmentIE-O-4EBHA


5.0 mm platform

Endopore 01WB (turquoise label), Endopore Hybrid and Entegra 03WB. 0.9 mm high × 2.7 mm hex, metric thread.

IE-5EHAHealing abutmentIE-5EHACross-ref: 02WB-3HS, 02WB-5HS +3IP-5SLIAFStraight abutment, 6 mm flareIP-5SLIAFCross-ref: 05WB-7FS, 05WB-7FN +4T-5ESA-IPSimple Step abutmentT-5ESA-IPIP-5IICImpression coping, open trayIP-5IICCross-ref: 06WB-CTCA/S, 06WB-CTCA/SL +1IP-5IAImplant analogIP-5IACross-ref: 06WB-IA/1, 06WB-IA +2IP-5EPSUCLA plastic sleeve, hex and non-hexIP-5EPSCross-ref: 06WB-UCLA/H, 06WB-UCLA +2IE- 5EBHABall abutmentIE- 5EBHACross-ref: 04WB-1ORS, 04WB-2ORS +4IE-5EBHA-TBall abutmentIE-5EBHA-TIE-5EBHA-BLBall abutmentIE-5EBHA-BL
Innova part number cross-reference (28)
Innova part number cross-reference
Innova part Description Titan part
02WB-3HS Straight healing abutment, H 3, 5.0 EP IE-5EHA
02WB-5HS Straight healing abutment, H 5, 5.0 EP IE-5EHA
02WB-7HS Straight healing abutment, H 7, 5.0 EP IE-5EHA
02WB-4H Flared healing abutment, H 4, 6.8 EP IE-5EHA
02WB-6.5H Flared healing abutment, H 6.5, 6.8 EP IE-5EHA
06WB-CTCA/S Straight transfer coping, 11 mm IP-5IIC
06WB-CTCA/SL Straight transfer coping, 16 mm IP-5IIC
06WB-CTCA/F Flared transfer coping IP-5IIC
06WB-IA/1 Implant analog, aluminum IP-5IA
06WB-IA Implant analog, aluminum, 5 pack IP-5IA
06WB-PIA Implant analog, stainless IP-5IA
06WB-PIA/5 Implant analog, stainless, 5 pack IP-5IA
05WB-7FS Straight hexed abutment IP-5SLIAF
05WB-7FN Straight hexed abutment IP-5SLIAF
05WB-9FS Straight hexed abutment IP-5SLIAF
05WB-9FN Straight hexed abutment IP-5SLIAF
05WB-11FS Straight hexed abutment IP-5SLIAF
05WB-11FN Straight hexed abutment IP-5SLIAF
06WB-UCLA/H UCLA, hexed IP-5EPS
06WB-UCLA UCLA, non-hexed IP-5EPS
06WB-UCLA/H/G Gold UCLA, hexed, all-plastic alternative IP-5EPS
06WB-UCLA/G Gold UCLA, non-hexed, all-plastic alternative IP-5EPS
04WB-1ORS O-ring abutment, 1 mm cuff IE- 5EBHA
04WB-2ORS O-ring abutment, 2 mm cuff IE- 5EBHA
04WB-3ORS O-ring abutment, 3 mm cuff IE- 5EBHA
04WB-4ORS O-ring abutment, 4 mm cuff IE- 5EBHA
04WB-5ORS O-ring abutment, 5 mm cuff IE- 5EBHA
04WB-6ORS O-ring abutment, 6 mm cuff IE- 5EBHA
Innova implant numbers for 5.0 mm (24)

Screws, guide pins, locator pins and ball abutment accessories: see accessories

More Innova categories

One-stageAccessoriesAll Innova

Not sure which part fits? 1-201-439-0470

Which 4.1 mm Endopore implant do I have?

Check the label. 01B numbers in a green box (2000 and later) use the industry-standard hex. Original 01 numbers in a grey box have a 0.9 mm hex and UNF thread and need the pre-2000 parts.

Which platform is an Entegra 3.25 mm implant?

It depends on the series: 03M (red label) restores on 3.5 mm, and 03B (green label) restores on 4.1 mm.

How fast do orders ship?

Orders placed by 4:00 PM ET ship the same day.

Innova®, Endopore®, Entegra® and other implant system names are trademarks of their respective owners. Titan Implants, Inc. is not affiliated with or endorsed by them. Part numbers are listed only to identify compatibility.
